B4001 SERIES
Product Description
B4001 Series tape is a white double-sided synthetic rubber adhesive tape without carrier, which is specially formulated to be removed via stretch release and without adhesive residue and breaking.
Features
✔ High Bond Strength
✔ Stretch Release
✔ Easy Die-Cut
✔ RoHS Compliant & Halogen Free
Applications
B4001 Series tape can be used in a wide range of bonding applications that require components to be permanently bonded together under normal use but removable for repair or re-work. Commonly used for securing MHH batteries to enclosures.
Typical Properties
| Part Number | B4001-010 | B4001-015 | B4001-020 | B4001-025 | B4001-50 | B4001-100 | Test Method |
| Available Thickness (mm) | 0.10 | 0.15 | 0.20 | 0.25 | 0.50 | 1.00 | ASTM D3652 |
| Color | White | – | |||||
| Type of backing | None | – | |||||
| Type of adhesive | Synthetic Rubber | – | |||||
| 1800 Peel to Steel
(gf/inch @20min RT) |
2000 | 2000 | 2500 | 2500 | 2800 | 3200 | ASTM D3330 |
| Tensile Strength (gf/inch, MD) | 4000 | 4500 | 4600 | 4600 | 8000 | 9000 | ISO 1798 |
| Tensile Strength (gf/inch, CD) | 4000 | 4500 | 4600 | 4600 | 8000 | 9000 | ISO 1798 |
| Elongation (%, MD) | 900 | 900 | 1000 | 1000 | 1000 | 1000 | ISO 1798 |
| Elongation (%, CD) | 900 | 900 | 1000 | 1000 | 1000 | 1000 | ISO 1798 |
| Operating Temperature (°C) | -20～85 | – | |||||
| Standard Size (mm x m) | 1000*50 | – | |||||
